NOTE:

Secure the a/c vent, climate

control, hazard switch, and the pas­

senger air bag on/off light into the

99-7871 radio housing panel using

the factory hardware. (Figure A)

1

Remove the center bar from the 99­

7871 radio housing, (Figure B)

2

Attach the corresponding bracket to

the DDIN head unit. (Figure C)

3

Insert the DDIN trim plate into the

radio housing. (Figure D)

4

Position the bracket/radio assembly

to the back of the radio housing and

secure with the (8) Phillips screws

provided. (Figure D)

KENWOOD

Installation Manual
Double DIN Kit

anthracite: CAW 2130-04
taupe:

CAW 2130-05

Honda Civic Hybrid 2006 ->

Compatible with these Kenwood double DIN devices

Kenwood Navigation
