KENWOOD
2-
din
Listen to the Future
CAW-1201-05
^ ^ ^
Remove the dashboard panel at the loca
tion of the arrows.
Remove the CD player. This is tighten by
two screws
Remove the original radio.
Remove the original plastic mounting
frame at the location of the arrow/ cross.
You must remove 2 mm off original frame
at the top arrows marked with 1.
Place the replacement frame and the
original dashboard panel.
Connect all of the needed wiring harnesses and check the connections carefully.
