KENWOOD
2-
din
Listen to the Future
CAW-1201-05
Installation manual for:
Mitsubishi CZ3 2005 -->
InstaNation kit includes the fcNowing items:
* 1X 2-ISO 100 mm. metal bracket
* 1X Replacement frame
* 1X Radio trim
* 2X Mounting plates
* 2X Mounting spacers
* 4X Screws
* 2X Cushion
* 2X Radio removal keys
Kenwood DDX6029
We advice to use the following positions.
Other positions are also possible.
Use position 2 marked with a cross.
Use position 6 & 8 marked with an arrow.
Measured fTom lei^ to right.
Kenwood DDX 7025
We advice to use the following positions.
Other positions are also possible.
Use position 1 marked with a cross.
Use position 14 & 16 marked with an arrow
Measured from lei^ to right.
* Mount the plates.
