Crest Audio Stereo Amplifier - Manual (Page 8)

Page 6 Crest Audio Pro Series Power Amplifiers
Ch B
-1
0dB
-3
-6
-10
-15
-30
-80
Ch A
-1
0dB
-3
-6
-10
-15
-30
-80
8001 Professional Power Amplifier
Clip/Limit
Signal
Temp/DC
Active
IN B IN A
PIN 3+
A
B
STEREO
BRIDGE
PARALLEL
SIGNAL
GROUND
LIFT
--
OUT A
+
--
OUT A
+
+
BRIDGE
--
+
BRIDGE
--
+
OUT B
--
+
OUT B
--
USA ONLY
MODEL #
8001 30 AMPS
MAXIMUM
INPUT CURRENT
@ 120V, 60Hz
OUTPUT POWER
IN WATTS PER
CHANNEL, 2 Ω
1400W
OUTPUT - CLASS 1 WIRING MAY BE USED
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
AVIS : RISQUE DE CHOC ÉLECTRIQUE—NE PAS OUVRIR
Designed & manufactured in the USA by:
Crest Audio Inc.
100 Eisenhower Dr.
Paramus, New Jersey 07652 USA
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
ATTENTION! POUR ÉVITER LE RISQUE D'INCENDIE OU DE CHOC
ÉLECTRIQUE, NE PLACEZ PAS CET APPAREIL SOUS LA PLUIE OU Á
L'HUMIDITÉ
PUSH PUSH
2 3 1
7 8 9 5 6 4
1-Front Panel Channel Clip/Limit, Signal, Temp/DC, and Active LEDs. 2-Combination Circuit Breaker/Power Switch.
3-Heated Air Exhaust Grill. 4-Mode Select Switch. 5-XLR Input Connectors. 6-Crest Audio Octal Socket Accessory Connectors.
7-Channel A & B Attenuators. 8-Five-Way Output Binding Post Connectors. 9-Signal Ground Lift Barrier Strip.
Model 8001 Features
