IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock and
injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces. If provided, use handles when moving
this heater.
Fire Hazard. Keep electrical cords and com-
bustible materials, such as drapes and other
furnishings, away from heater.
3. Extreme caution is necessary when any heater is used by or
near children or handicap individuals and whenever the heater
is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or
after the heater malfunctions, has been dropped or damaged in
any manner. Return heater to authorized service facility for
examination, electrical or mechanical adjustments, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in wet or moist locations.
8. Do not run cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from traf-
fic area and where it will not be tripped over.
9. To disconnect heater, turn controls off, then remove plug from
outlet.
NOTE: HF303E DC, HF303EG DC and HF403E DC heaters
contain an integral fan delay. To de-energize these heaters, turn
toggle switch to the off position and allow heater to run until fan
stops, then remove plug from outlet.
10. Connect to properly grounded outlets only.
11. Do not insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock, fire or
damage the heater.
12. To prevent a possible fire, do not block air intakes or exhaust
in any manner. Do not use on soft surfaces, like a bed, where
opening may become blocked.
13. Do not use it in areas where gasoline, paint or flammable liq-
uids are used or stored.
14. Use this heater only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock or injury to persons.
15. This heater is not intended for use with an extension cord.
Plug the cord directly into an appropriate wall receptacle.
Model
Model Volts Watts
Heating
Motor Resistor Contactor Switch
Power Cord Fan Fan
Number Element Set Delay Blade
HF203G (AC) C 120 1,900 357-050025-011 193-302120-001 ———— ———— 292-046123-001 075-510656-004 ———— 112-047282-002
HF203G (AC) C 240 2,000 357-050025-002 193-302120-001 ———— ———— 292-046123-001 075-510656-002 ———— 112-047282-001
HF303G (AC) C 240 3,000 357-050025-005 (2) 193-302120-001 ———— ———— 292-046123-001 075-510656-005 ———— 112-047282-001
HF303H (AC) C 120 3,000 357-050025-006 (2) 193-302120-001 ———— ———— 292-046123-001 075-510656-008 ———— 112-047282-002
HF403G (AC) C 240 4,000 357-050025-002 (2) 193-302120-001 ———— ———— 292-046123-001 075-510656-006 ———— 112-047282-002
HF203EG (DC) E 120 1,900 357-050025-001 193-036526-004 ———— 072-057039-001 292-046123-002 075-510656-007 ———— 112-047282-001
HF203DG (DC) E 240 2,000 357-050025-002 193-036526-004 236-047351-001 072-057039-002 292-046123-002 075-050028-006 ———— 112-047282-001
HF303E (DC) E 120 3,000 357-050025-006 (2) 193-036526-004 ———— 072-057039-001 292-046123-002 075-050028-007 300-048038-001 112-047282-001
HF303DG (DC) E 240 3,000 357-050025-005 (2) 193-036526-004 236-047351-001 072-057039-002 292-046123-002 075-050028-016 300-048038-001 112-047282-001
HF403E (DC) E 240 4,000 357-050025-002 (2) 193-036526-004 236-047351-001 072-057039-002 292-046123-002 ———— 300-048038-001 112-047282-001
RENEWAL PARTS IDENTIFICATION
Parts Common to All Heaters
Cutout 300-049200-004
Handle 139-050027-001
Rubber Feet 125-013031-002 (4)
NOTE: Parts suffixed by a number ( ) indicates quantity used.
