Gw4500 – Campbell Hausfeld Welder / Generator GW4500 User Manual
Page 19
19
www.chpower.com
GW4500
For replacement parts or technical assistance,
call 1-800-543-6400
1
Alternator - 4kW, 140A AC (includes items 2 through 22)
GW001000AV
1
2
Engine
Adapter
GN002301SV
1
3
Rotor Tie Rod
GN002304SV
1
4
Nyloc Nut - M8-1.25
▲
5
5
Diode, Suppressor, Capacitor Kit (2 each)
GN002337SJ
1
6
Air Outlet Guard
GN002310SV
2
7
Retaining
Ring
GN002311SV
1
8
Bearing
GN002312SV
1
9
Stud - M8-1.25 x 30mm
GN002313SV
4
10
Phillips Head Screw - M5-0.8 x 10mm
▲
8
11
Phillips Head Screw - M6-1.0 x 10mm
▲
4
12
Serrated Flange Nut - M6-1.0
▲
4
13
Inductor
GW001050SV
1
14
Capacitor - 35mF, 450V
GW001016SV
1
15
Hex Head Screw - 3/8-16 x 1 inch
▲
4
16
Alternator
Fan
GW001020SV
1
17
Top
Cover
GW001002SV
1
18
Dinse Socket - 200A
WC000300AV
2
19
Commutator Knob - Small
WC400401AV
1
20
Commutator - Output
GW001045SV
1
21
Commutator Knob - Large
GW001046SV
1
22
Commutator - Gen/Weld
GW001047SV
1
23
Circuit Breaker - 25A, 250V
GN003601AV
2
24
Endbell with Nutcover - GFCI, T-lock
GN002480SJ
1
25
Twistlock Receptacle - 125/250V, 20A
GN003501AV
1
26
Duplex Receptacle - 120V, 20A
GN003403AV
1
27
Nylock Nut - #8-32
▲
4
28
Hex Head Screw - #8-32 x .75 inch
▲
4
▲ Standard hardware item, available at local hardware stores
Replacement Parts List
Ref. No.
Description
Part Number
Qty.
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Campbell Hausfeld
Attn: Parts Dept.
100 Production Drive
Harrison, OH 45030 USA
