9F426-03 Module Specific Information
10
Full Duplex Configuration Screen
The Full Duplex Configuration Screen (Figure 4), allows you to specify transmit
and receive settings for the module’s front panel ports.
Figure 4. Full Duplex Configuration Screen
SmartSwitch 9000 Local Management
Full Duplex Configuration
Module Name: 9F426-03 Firmware Revision: 01.04.10
Slot Number: 9 BOOTPROM Revision: 01.02.00
PORT# OPERATION MODE LINK STATUS PORT STATUS
1 FULL DUPLEX No Link ENABLED
2 FULL DUPLEX No Link ENABLED
3 FULL DUPLEX No Link ENABLED
SAVE SET ALL PORTS: FULL EXIT RETURN
