9F426-03 Module Specific Information
8
Switch Configuration Screen
The Switch Configuration Screen (Figure 3), displays parameters you can
configure to make the switch operational.
Figure 3. Switch Configuration Screen
SmartSwitch 9000 Local Management
Switch Configuration
Module Name: 9F426-03 Firmware Revision: 01.04.10
Slot Number: 9 BOOTPROM Revision: 01.02.00
Switch Address: 00-00-1D-00-08-45 Type of STA: [NONE]
Numbers of Ports: 4
Port # MAC Address State Status
1 00-00-1D-00-08-45 disabled [DISABLED]
2 00-00-1D-00-08-46 forwarding [ENABLED]
3 00-00-1D-00-08-47 forwarding [ENABLED]
4 00-00-1D-00-08-48 forwarding [ENABLED]
SAVE EXIT RETURN
Port # refers to the following:
•
Port 1 - INB
•
Port 2 - Front Panel Port 1
•
Port 3 - Front Panel Port 2
NOTE
