Casio EXILIM EX Z 33 - Manual (Page 55)

55
Advanced Settings
*5 (m)
NOTE
• Above values are for reference only.
For movie macro, the focus range is a few centimeters within the center distance.
To focus with manual focus
1.
On the monitor screen, compose the image so
the subject you want to focus on is within the
yellow boundary.
2.
Watching the image on the monitor screen use
[4] and [6] to adjust focus.
• At this time the image that is within the boundary
will enlarge and fill the monitor screen, which aids
in focusing. If you do not perform any operation for
two seconds while the enlarged image is displayed,
the screen in step 1 will re-appear.
Normal Macro
Zoom Steps Close Up Telephoto Center distance
Z1 (Wide) Approx. 0.71 (2.3 ' )
9
0.30 (11.8 ")
2 Approx. 0.94 (3.1')
9
0.30 (11.8 ")
3 Approx. 1.33 (4.4')
9
0.30 (11.8 ")
4 Approx. 1.74 (5.7')
9
0.32 (12.6 ")
5 Approx. 1.95 (6.4')
9
0.35 (13.8 ")
6 Approx. 3.09 (10.1')
9
0.40 (15.7 ")
7 (Tele) Approx. 3.51 (11.5')
9
0.45 (17.7 ")
Yellow boundary
