Crate Amplifiers PALOMINO V32H - Manual (Page 12)

V32H
GUITAR AMPLIFIER HEAD
V32H TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 30 Watts RMS @ 6 % THD, 8 ohm load, 120 VAC
SIGNAL TO NOISE RATIO 71dB Typical
GAIN Clean 56dB, Overdrive 101dB
TREBLE 12dB range @ 6kHz
BOOST +10db @ 900Hz
MID 10dB range @ 1kHz
BASS 8dB range @ 150Hz
PRESENCE +8dB @ 10kHz
PREAMP TUBES (3) 12AX7A
POWER AMP TUBES (4) EL84
POWER REQUIREMENTS 120 VAC, 60 Hz, 35VA
100/115 VAC, 50/60 Hz, 35VA
230 VAC, 50/60 Hz, 35VA
SIZE AND WEIGHT 21” W x 7-3/4” H x 8-1/8” D, 25.5 lbs.
The V32H is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Specifications and information in this manual are subject to change without notice.
www.crateamps.com
©2005 St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133
47-399-02 • 110405
