Page 6
systems connection (Stereo and 5.1)
1) Before connecting, make sure to turn off power of all apparatus.
2) After finishing connection, turn on the power again.
AV cable (accessory) should be connected by color .
Yellow plug-------- video terminal (yellow)
White plug--------- left audio terminal (white)
Red plug----------- right audio terminal (red)
Must connect properly, especially the plug should be inserted to the bottom.
4
DIGITAL AUDIO INPUT
OPTICAL
COAXIAL
SUB
WOOFER
CENTER
FRONT
R
L
5.1 CHANNEL INPUT
5.1 channel
amplifier
SURROUND
INPUT
S-VIDEO
A B
VIDEO
L
COMPONENT
VIDEO INPUT
Cb/Pb
Cr/Pr
Y
R
