I Dimensions I
42-1/8(1070)
iTerminai Configuration I
i Specifications i i Computer input Signai I
Effective Screen Size (W x H) 37-1/2" X 21-3/32" (952.3 X 536.1 mm)(43in. Diag.)
Aspect Ratio 16:9
Number of Pixeis 1024 (Hor.)x768 (Ver.)
Pixel Pitch 0.930 (Hor./RGB trio) x 0.696 (Ver.) mm
Coior Resoiution 1024 grey scaie, 1.07biilion coiors
Brightness llOOcd/m^ (white peak)
Dimensions (W x H x D‘) 42-1/8" X 24-13/16' X3-27/32' (1070 x 630 x 98 mm)
Weight 72 lbs. 12oz(33 kg)
Power Consumption 298W (0.8W at stand by)
Power Requirements AC100-120V±10% 50/60HZ
Operating Temperature 32*F-104*F(0'C-40*C)
Operating Humidity 20%-80%
Safety Reguiations UL 1950, FCC 15B class B, C-UL
*Not including handles
lInput/Output Terminaisi
*Not compatible with Copy Protection (HDCP)
iAudio input/Output Terminaisi
iControi Terminaisi
Connector Signal Level/Impedance
INPUT 1 IN Mini D-sub
15-pin
Analog RGB Signal
(G on Sync compatible)
RGB : 0.7Vp-p/75Q
G on Sync : 1Vp-p/75Q
HD/CS,VD : TTL Iev6l^.2k£2
Compatible with Microsoft Plug & Play (VESA DDC 1/2B)
OUT Mini D-sub
15-pin
Analog RGB Signal
(G on Sync compatible)
75 D
INPUT 2 IN DVI-D
24 Pin
Digital RGB Signal (DVI Standard)*
Compatible with Microsoft Plug & Play (VESA DDC 2B)
Connector Level/I mpedance
AUDIO INPUT(INPUTI) IN Stereo mini L/R: 500mVrms/more than lOkQ
AUDIO INPUT(INPUT2) IN Stereo mini L7R: 500mVrms/more than lOkO
AUDIO OUTPUT OUT Stereo mini L/R: 500mVrms/less than 5kO (FIX)
L/R: 0-500mVrms/less than 5kO (VARIABLE)
SPEAKER OUT L/R: 8-16Q/7W +7W(8fi)
Resolution
(dot X line)
Vertical
Frequency
Horizontal
Frequency
Digital RGB Usage
640x400 56.4Hz 24.6kHz NEC PC-9800
720x400 70.1Hz 31.5kHz NEC PC-9800
85.1Hz 37.9kHz
640X460 6DHz 31.5kHz YES
66.7Hz 35.0kHz Apple Macintosh 13"
72.8Hz 37.9kHz
75Hz 37.5kHz
8SHz 43.3kHz
846X460 6DHz 31 .OkHz YES
800x600 56Hz 35.2kHz YES
60Hz 37.9kHz YES
72Hz 48.1kHz
75Hz 46.9kHz
85Hz 53.7kHz
832x624 74.6Hz 49.7kHz Apple Macintosh 16"
1024x766 60Hz 48.4kHz YES
70Hz 56.5kHz
75Hz
(74.9Hz)
60.0kHz
(60.2kHz)
() Indicates Apple Macintosh 19*
85Hz 68.7kHz
1280x768* 56Hz 45.1kHz YES
60Hz 47.8kHz YES
70Hz 56.1kHz
1152X864* 6DHz 53.7kHz YES
72Hz 64.9kHz
75Hz 67.5kHz
1152x870* 75.1Hz 68.7kHz Apple Macintosh 21"
1152x900* 66Hz 61.8kHz Sun Microsystems LO
76Hz 71.7kHz Sun Microsystems HI
1280x960* 60Hz 60.0kHz YES
1260x1024* 60Hz 64.0kHz YES
75Hz 60.0kHz
8SHz 91.2kHz
1400x1050* 60Hz 65.3kHz YES
75Hz 82.3kHz
85Hz 93.9kHz
1600x1200* 60Hz 75.0kHz
6SHz 81.3kHz
70Hz 87.5kHz
75Hz 93.8kHz
85Hz 106.3kHz
RS-232C
(for control Of computer)
Connector D-sub 9 Pin
Baud Rate 1200,2400,4600,9600, 19200,36400 bps
Combination IN/OUT Connector Mini DIN 6 Pin (x2)
*Compressed or partisi dispiay
■ Accessories
Power Code x 1, Remote Control Unit x 1, Remote Control Unit Holder x 1, AA(R6) batteries x 2,
Cleaning cloth(for screen) x 1, Speed clamps x 2, Bead bands x 2, Display stands x 2,
Washers x 2, Hex hole bolts(M8x40) x 2, Operating Instructions x 1, Warranty x 1
•Notice
‘ This equipment is soid on the condition that it wiii be instaiied by a competent professional engineer with sufficient training and skiii to carry out
proper Installation. Be sure to entrust the installation and setup of this machine only to a competent professional or retail service engineer.
• Pioneer cannot accept liability in case where the equipment Is damaged due to inappropriate Installation location, Improper assembly, instailatlon,
set-up, operation or renovation, or by naturai disasters.
