Crown Boiler BB100H User Manual
Page 6
4
5
Table 2.3: Connections
Key Model
BB100H
BB100I
BB100C
A
From Boiler Supply
1” Copper
B
To Boiler Return
1” MPT
C
To System
1” Copper
D
From System
1” Copper
E
Expansion Tank/Fill
1/2” FPT
F
Air Vent
1/2” FPT
G
To Indirect Water Heater
1” Copper
H
From Indirect Water Heater
1” Copper
I
DHW Inlet Connection
1/2” MPT
J
DHW Outlet Connection
3/4” MPT
Table 2.4: BB100C DHW Performance
Boiler Model
DHW Production (GPM) Approximate
Response Time (s)
Approx. DHW Set
point Range
77 Rise
90F Rise
to 100F
to 120F
BWC070
1.5
1.3
80
120
104 - 140
BWC090
2.1
1.8
70
100
104 - 140
BWC120
2.7
1.8
1
70
90
104 - 140
BWC151
2.9
1.8
1
70
90
104 - 140
Table 2.4 Notes:
At 90 degree rise, boiler input (and therefore DHW production) is reduced due to proximity of DHW outlet
1.
temperature to maximum permitted target supply temperature.
Response time is time required to reach specified temperature from a “cold start” with DHW inlet temperature of
2.
58F and a 1.0 GPM draw rate. Additonal time may be required to purge the piping between the Bimini Buddy and
the fixture.
