INSTALLING THE REPLACEMENT DVD-ROM DRIVE
DVD-ROM
INSTALLING THE REPLACEMENT DVD-ROM DRIVE
DVD-ROM
2. Remove the CD-ROM drive.
• Disconnect the two connectors on the
left side, and the one connector on the
right side,
• Remove the two screws at left and
right,
• Pull out the drive straight in alignment
with the changer's right and left guides.
2. CD-ROM
• eiil
09iljT
• (DhL-h}(0'f3'^ Klt-ynoTTv ^1
3. Insert the Replacment DVD-
ROM drive.
• Slide the drive along the left and right
guides of the Changer and insert into
the half of it.
DVD-ROM
4^mzxnz
4. Complete installation of
the replacement DVD-ROM
drive:
• Reconnect the two wiring connectors
on the left, and the one on the right.
Note:
The colour of the harness (wire) of drive
No. 4 (top drive) is black, and that of
the harness (wire) of drive No. 3
(second from the top) is blue, the
harness (wire) of drive No. 2 (third from
the top) is yellow, the harness (wire) of
drive No. 1 (fourth from the top) is red.
• Be sure the drive has been fully inserted
into its slot, then secure it in place with
the two screws at left and right.
• Secure the wiring harnesses in place,
adjusting them out of the way of other
parts. Refer to the other installed drives
for the proper method of securing the
harnesses.
4.55iSfflDVD-ROM
3
■
x^zy'No.4 (m±m) coj{-^^x (mw
0&im. H^zyNo.3 (±^'62^S) (D
J\~T^X
ms) (Dj\-y~x
(±&54ms)
-O i: :E a 2 A F/ t A y Ih fid ^ L/r < Tc A
Do not change the positions of these
switches which are intended for use in
servicing,
