PARTS AND FEATURES
Upper level wash
ULTRA FLOW ^
water feed tube
Model and serial number label
Water inlet opening
Heating element
Rinse aid dispenser reduces spotting
and improves drying.
Detergent dispenser
Active vents
TurboZone''- rotating spray jets blast
water into every corner to eliminate
soaking and scrubbing of dirty
baked-o.n soils.
Pressurized spray nozzles and variable
speed motor provide effective cleaning.
Lower spray arm
Overfill protection float
Ultra
M/as/7®%
fitter removes soil from
water and improves cleaning action.
Top rack adjusters
(one on each side)
Flexible tines
Middle spray arm
Fold-down tines ■
Knife holder
Control panel
.....-
Utensil basket
No-flip clip
Cup shelves
Silverware basket
TOP RACK
Silverware basket
BOTTOM RACK
