PARTS AND FEATURES
ri
8
10
11
12
13
1. Top rack
2. Spray tower protector
3. Bottom rack
4.
Spray arm
5. Water inlet opening [in tub wall]
6. Rack bumper
7. Heating element
8. Vent
9. Silverware basket
10. Model and serial number label
11. Overfill protection float
12. Detergent dispenser
13. Rinse aid dispenser
Control Panel
/■--------
\
HEAT NO HEAT
DRY DRV
II
V_____
CYCLES
OPTIONS j
POTS ft PftNS
