SIREN SWITCH
This momentary push-button switch provides Horn or Manual tone control.
It can optionally control Horn Ring Cycler 2 operation in the Standby position
if the HRC2 option is selected.
Horn - A simulated Air-horn tone momentarily sounded.
Manual Wail - Manual control of Wail tone rise and fall.
Manual Mech - Manual control of Mech tone rise and fall.
The Siren push-button optionally provides the following function while in Standby mode.
See OPTION SWITCHES section.
DIP
SW-3
DIP
SW-4
Siren push-button and Auxiliary Input Function
with Rotary Selector Switch in Standby
OFF
OFF (Default) Produces Horn tone while pressed.
ON
OFF Manual control of Mechanical tone.
Also Mechanical tone continues to fall when Rotary
Selector Switch is changed from Mechanical position.
OFF
ON
Manual control of Wail tone.
ON
ON
Activates Horn Ring Cycler 2 (HRC2) function.
AUXILIARY INPUT
During installation an auxiliary input may be connected to the horn ring or other switching
device. It provides the same operation as pressing the Siren push-button.
HORN RING CYCLER 2 (HRC2)
During installation, the auxiliary input must be connected and the HRC2 option selected. While
the siren is in standby, tap the horn ring for different tones.
See OPTION SWITCHES section for further details.
RADIO VOLUME ADJUST
The radio repeat volume level is set using an adjustment on the side
of the amplifier. Set the Selector Switch to the Radio position and
turn on the power. With the radio volume itself set to a normal level,
set the siren radio volume adjust control to the desired level.
DUAL SWITCH
The Dual switch controls the signal to the two amplifiers. With the switch off,
the amplifiers produce a common signal to the speakers. With the switch on,
independent siren signals are produced by each amplifier as follows:
Selector Switch
Operating Mode Activate Siren push-button or Auxiliary Input Override
Spkr A
Spkr B
Spkr A and B
Radio Radio
No
Change
Standby Silent
Horn (Default) or Dual Man Mech or Dual Man Wail or HRC2
Mech Mech
Mech
Horn
(Default) or Dual Manual Mech
Wail Wail
Yelp
Horn
Yelp Yelp
Mech
Horn
Phaser Phaser
Mech
Horn
DUAL
O
N
O
F
F
Radio Volume
SIREN
