will flash 4 times for 4 th code. If all 4 codes are learned, the unit will automatically exit code-learning mode, otherwise turn
key off and close hood.
NOTE: When learning 2-Way LCD or 2-Way LED remotes, wait for the confirmation beep or LCD “Antenna Icon” message
before learning the next remote.
REMOTE PROGRAMMING DIAGRAM
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
(BLUE WIRE GROUNDED)
2-WAY SYSTEMS &
ONE WAY CS-2011RS
IGN
OFF
PRESS TOGETHER
LOCK &
UNLOCK
PRESS
LOCK ONLY
"SideKick" REMOTES
COMPLETE
ALARM TRIGGER DIAGNOSTICS
This systems includes disarm diagnostics, through the LED light, that will help in determining what caused the last
trigger of the alarm system. This is a valuable tool in determining how the vehicle was tampered with or if there is a
false alarm problem in which case you can make the necessary adjustments to correct the problem.
