background image

ìiìsta!!aiion Requirements (coniinued)-iMPOKrANT...piea^ Read cardùuy

Use of Adapter

Plug

Because of potential safety hazards
under certain conditions, we strongly

recommend against use of an adapter

plug. However, if you still elect
to use an adapter, where local

codes permit, a TEMPORARY
CONNECTION may be made to a

properly grounded two-prong wall

UliUCt

v y

U5C ui

a

vjju

auaptvi

(Fig. 2) available at most local

hardware stores.

TEMPORARY METHOD

(ADAPTER PLUGS NOT
PERMITTED IN CANADA)

Al

i AD^C

HI.IUI« L^nui;.

PRONGS/SLOTS

Fig. 2

INSURE PROPER

GROUND AND
FIRM CONNECTION
BEFORE USE

The larger slot in the adapter must

be aligned with the larger slot in

the wall outlet to provide proper

polarity in the connection of the
power cord.

CAUTION: Attaching the adapter

ground terminal to the wail outlet
cover screw does not ground the

appliance unless the cover screw is

metal, and not insulated, and the
wall outlet is grounded through the

house wiring. You should have the
circuit checked by a qualified

electrician to make sure the outlet
is properly grounded.

When disconnecting the power

cord from the adspier^ always hold
the adapter with one hand. If this

is not done, the adapter ground

terminal is very likely to break
with repeated use.

Should the adapter ground

terinlnal break, DO NOT USE the

appliance until a proper ground
has again been established.

Use of HAteiislon Cords

Because of potential safety
hazards under certain conditions,
we strongly recommend against the

Ul au VAiWllOlVll WWIU* *j.WTVTV4f

if you still elect to use an extension
cord, it is absolutely necessary that
it be a UL listed 3-wire grounding

type appliance extension cord having

n nm'/Miv^rlinfT

rhino' QtlH

a

w**v*w%

and that the electrical rating of the
cord be 15 amperes (minimum) and

120 volts. Such extension cords are

obtainable through your local

oArx/iAp» nraiini

7

i:itiAn

-

- -^^v*****..**ww**.

T

'

The refrigerator should always
be plugged Its own
individual electrical outlet—

(115 volt, 60 Hertz, or 100 volt, 50

Hertz, single phase AC). This is
recommended for best performance

8.n(i to prcVCIit overloading hOUSC

wiring circuits, which could cause
a fire hazard from overheating wires.

Refrigerator locatloo

Do not install refrigerator where
temperature will go below 60°E
because it will not run often enough

to maintain proper temperatures.

Do install it on a floor strong
enough to support a fuOy loaded
refrigerator.

Also see Energy-Saving Tips
regarding location.

Clearances

Allow the following clearances for
ease of installation and proper air

Ati

WJ.X V/UXU&-AV/XA •

Sides..................................... 3/4"

TU.«

1

"

lup.......................................... A

Back..........................................

V

When bnlliltiig a new home

Consider providing a water supply
to the refrigerator location. It will
simplify connection of an optional

automatic icemaker should you

wish

tn

install one,

at a later date.

Adjustable rollers, which enable
you to move your refrigerator away

from the wall for cleaning, are
located behind the base grille.
These rollers should be set so the

refrigerator is firmly positioned on

the floor and the front is raised just
enough that the doors close easily

when onened about halfway.

TV) adjust rollers, remove the base
grille by grasping it at the bottom
and pulling it out.

Turn roller adjusting screws
clockwise to raise the refrigerator,
counterclockwise to lower it. Use

adjustable wrench (3/8" hex head
bolt) or pliers.

When adjusting the front rollers

for proper door closure, it is
recommended that the bottom front
edge of the cabinet be approximately
3/4" from the floor.

nn hark nf trrille, with olamos itl

-------- ^------- -- ---------------------

cabinet and push forward until the
grille snaps into place.
