Whirlpool 8ET18DK - Manual (Page 11)

Adjusting the lateral-adjust shelf
To slide shelf side-to-side:
1. Lift slightly on shelf front.
2. Slide to desired location.
3. Lower shelf front to level position.
NOTE: You do not have to remove small
items from the shelf before moving it side-to-
side. You may need to remove larger items.
Lift front slightly.
Then slide to new location.
To remove the shelf:
1. Remove all items from the shelf.
2. Hold back of shelf with one hand.
3. Lift front of shelf to 45° angle.
4. Lower shelf slightly to release shelf from
upper channel of track. Then pull shelf
straight out.
NOTE: Shelf is heavy. Make sure you use
both hands when removing shelf.
Upper channel
Hold with both hands
and lift front to 45° angle.
To remove shelf track:
1. Lift both sides of track slightly.
2. Pull track straight out.
Hold both sides and
lift up and out.
To replace shelf track:
1. Guide track hooks into the shelf support
slots on the back wall of the cabinet.
NOTE: Make sure all three track hooks
are in slots and that the slots are parallel
to each other.
2. Push track backward and down.
3. Check that track is completely seated in
the shelf supports.
Make
sure all
3 sets of
hooks
are in
support
slots.
Shelf
\ support
10
