Page 7: Removing the crispers and crisper cover. 7, Adjusting the crisper humidity control
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Pull out to the stop,
~ lift the front
and pull again.
Remove the
glass insert,
lift the frame front,
then the back.
Removing the crispers and crisper cover
To remove the crispers:
1. Slide crisper straight out to the stop, lift front,
then slide the rest of the way out.
2. Replace in reverse order.
To remove the cover:
1. Push up glass insert from bottom, then slide
out with both hands.
2. Lift front of cover frame.
3. Lift out cover frame by pulling up and out.
4. Remove metal cover support.
To replace the cover:
1. Replace metal cover support on wall supports
in front section of cabinet.
2. Fit back of corner into notch supports on walls
of refrigerator, then lower into place.
3. Slide back of glass insert into place, then
lower front.
Adjusting the crisper humidity controi
You can control the amount of humidity in the
moisture-sealed crisper.
1. The control can be adjusted to any setting
between LOW and HIGH.
2. LOW (open) lets moist air out of crisper for best
storage of fruits and vegetables with skins.
3. HIGH (closed) keeps moist air in the crisper for
best storage of fresh leafy vegetables.
Pull out to the stop, lift the
front and puil again.
Moving the meat drawer and cover
To remove the meat drawer:
1. Slide the meat drawer out to the stop.
2. Lift the front.
3. Slide the drawer the rest of the way out.
4. Replace in reverse order.
To remove the cover:
1. Tilt front of cover up, lift at back, and pull
straight out.
2. Replace in reverse order.
