C A R I N G F O R Y O U R D E H U M I D I F I E R

5. Remove the rear grille by pulling it out at

the bottom and dropping it down.

6. Lift the cabinet off the base.

7. Brush the coils clean, if necessary, with

warm water and a mild detergent. Rinse

and dry thoroughly.

Be sure the power

supply cord is disconnected from the

electrical outlet.

NOTE: The compressor is sealed and
needs no oiling.

8. The fan motor is permanently lubricated

and does not require further oiling.

Wash all plastic parts with a soft cloth,
warm water, and a mild detergent.

Rinse and dry them with a soft cloth.

Replace the cabinet and grille(s).

Reconnect the dehumidifier to power

supply.

Coils
