Whirlpool EHC511 - Manual (Page 2)

BEFORE OPERATING THE ICE MAKER
It is your responsibility to make sure that the ice
maker:
" has been installed where it is protected from
the elements.
• is located so that the front is not blocked to
restrict incoming or discharge air flow.
• is properly leveled.
•
is located in a well ventilated area with tem­
peratures above 55°F (13°C) and below 110°F
(43°C). Best results are obtained at temperatures
between 70°F (21°C) and 90°F (32°C).
is properly connected to a water supply and
drain.
is properly connected to electricity. A 11 5 Volt,
60 Hz.. 15 amp fused electrical supply is required.
NOTE: Time delay fuse or circuit breaker is
recommended.
is properly electrically grounded.
is not operated by anyone unable to use it
properly.
is used only for the job it was designed to perform,
is properly maintained.
ICE MAKER OPERATION
How it makes ice:
1. vVater is constantly circulated over a freezing
plate. As the water freezes into ice the minerals in
the v\,ater are rejected. This produces a clear sheet
of ice with a low mineral content.
4. Fresh water enters the machine for the next ice
making cycle.
5. Cubes fall into the storage bin. When the bin is
full the ice maker shuts off automatically and re­
starts when more ice is needed.
2 When the desired thickness is reached, the ice
siieet is released and slides on to a cutter grid. The
grid divides the sheet into individual cubes.
3 The water containing the rejected minerals is
drained after each freezing cycle.
