If the steps for using the Automatic
MEALTIMER Clock are not followed in
order, the electric oven door lock may be
turned on. The door will then either:
• not open:
• not close all the way (the oven light stays
on).
If the Door Won’t Open:
1. Make sure the Clock and Start and
Stop Times are set to the right time of
day.
2. Turn the Oven Selector to CLEAN.
3. Push in and turn the Stop Time Knob
past the right time of day,
4. Walt 30 seconds.
5. Turn the Oven Selector to OFE; the door
will be unlocked within 10 seconds.
If the Door Won't Close:
1. Make sure the Clock and Start and
Stop Times are set to the right time of
day: open the oven door.
Turn the Oven Selector to CLEAN,
Push in and turn the Stop Time Knob
past the right time of day.
Push the automatic oven light switch in
and hold it in for 10 seconds.
Let the oven light switch go and turn the
Oven Selector to OFF.
Push in the automatic oven light switch
and hold it for another 10 seconds.
Close the oven door
THE OVEN LIGHTS
Both oven lights will come on when you push the Light Switch, Push the
switch again to shut them off. Both lights will also come on when an oven door is
opened.
To replace the upper oven light bulb:
Turn off the electric power
at the main power supply.
4. Replace the bulb with a
40'watt appllar>ce bulb
available from most gro­
cery, variety and
hardware stores.
2. Remove the bulb cover by
pulling out on the wire
holder and moving it to the
side.
5. Replace the bulb cover
and snap the wire holder
in place The bulb must
have this cover when the
oven Is being used.
6 . Turn electrical power back
on at main power supply.
To replace the lower oven light bulb:
1. Turn oft the electric power
at the main power supply.
2. Remove the light bulb
from its socket.
THE OVEN VENTS
3. Replace the bulb with a
40-watt appliance bulb
available from most gro­
cery, variety and
hardware stores. Turn the
power back on at the
main power supply.
When the oven is on, hot air and moisture
escape through a vent on top of the control panel,
These vents are needed for air circulation.
Do not block the vents. Poor baking can result
