Whirlpool EV150F - Manual (Page 4)

Install properly...
1. Check the strength of the floor It should hold the
weight of a fully loaded freezer.
2 Pick a safe place, indoors, away from in­
flammables such as gasoline.
3. Allow 3 inches (7,5 cm) air space on top of freezer
for proper ventilation.
4. Allow at least an inch (2,5 cm) between the
freezer condenser, on the back of the unit, and
the wall.
5. Allow
'/2
inch (1.25 cm) on each side of the freezer
for ease of installation.
6. If the freezer is to be against a wall, you might
want to leave extra space on the hinge side so the
door can be opened wider
7. The four bolts that held your freezer in the shipping
crate are designed to be the levelling legs. Screw
the legs far enough Into the bolt holes. In each of
the four bottom corners, so the freezer stands
about 1 inch (2,5 cm) off the floor.
Level freezer...
so the door will stay
open at any position.
Levelling Leg
Lower Raise
Sfart adjusfmenf wifh the door hinge side.
1
. Slide freezer into place.
2. Adjust front legs to level the freezer.
- To raise front, turn each leg clockwise.
-To lower front, turn each leg counter-clockwise,
3. Check with level
4. After freezer is fully loaded, recheck with level
Remove sales labels...
Remove the Consumer Buy Guide label and any
inside labels before using the freezer.
To remove any remaining glue:
1. Rub briskly with thumb to make a ball, then
remove,
OR
2, Soak area with dishwashing detergent solution (1
teaspoon detergent in 1 quart warm water) be­
fore removing glue as described in step 1.
DO NOT USE rubbing alcohol or flammable or
toxic solvents, such as acetone, gasoline, car­
bon tetrachloride, etc. These can damage the
material.
NOTE: DO NOT REMOVE the Tech Sheet fas­
tened under the freezer at the front.
Clean it...
Clean your freezer before
using it. See cleaning
instructions on page 7,
Plug it in...
3-prong grounding
type wall receptacle
Retaining
Freezer
Power Plug 3-prong
grounding plug
Recommended Grounding Method
A115 Volt, 60 Hz., AC only 15 or 20 ampere fused
and properly grounded electrical supply is re­
quired. It is recommended that a separate circuit
serving only this appliance be provided.
Use a
receptacle which cannot be turned off with a
switch or pull chain. Do not use an extension
cord.
Attach retaining clip over power cord plug
from literature package inside the freezer.
