Parts list
# Part Number
Description
Qty
1
200100-BF
Motor Assembly - Black
Flat
1
2
250001
Bolt M6 x 20
4
3
250002
Washerø6, Flat
6
4
250003
Tie Bar
2
5
250004
Bushing Shaft
1
6
250005
Coupling Shaft
1
7
250006
Screw M5 x 6
1
8
250007
Drum Assembly
1
9
200700
Cable Assembly
1
10 250008
Rear Bush Drum
1
11 250009
Front Thrust Washer
1
12 250010
Gear Ring Output
1
13 250300
Gear Carrier Assembly
1
14 250011
Circlip
1
15 250012
Spring
1
16 250013-BF
Cover Clutch Housing -
Black Flat
1
17 250014
Bolt M6 x 70
2
18 GB2760BB16002-
SS
Radial Ball Bearing
16002 Sealed
1
19 250016-BF
Clutch Cap - Black Flat
1
20 250017
Washer ø6, Locking
1
21 250018
Bolt M6 x 16
1
22 250019
Axis Support Bushing
1
# Part Number
Description
Qty
23 GB2760BB06002-
SS
Radial Ball Bearing
06002 Sealed
1
24 250021
Clutch Bushing
1
25 250022
Above Clutch Axes
Washer
1
26 250023
Cam Clutch Gear
1
27 250024-BF
Gear Housing / End
Bearing - Black Flat
1
28 250025
Gear Ring
1
29 300022
Hand Saver Bar
1
30 250059-BF
Mounting Channel -
Black Flat
1
31 250029-BF
Roller Fairlead - Black
Flat
1
32 410022
Yellow Strap
1
33 200600
Switch Assembly -
Black
1
34 450021
Bolt M8 x 25
4
35 300020
Washer ø8, Locking
4
36 300019
Washer ø8, Flat
4
37 250033
Bolt M10 x 25
2
38 250034
Washer ø10, Flat
2
39 250035
Washer ø10, Locking
2
40 250036
Locking Nut M10
2
41 C20002
1/4" Clevis Hook
1
