REV 10020-20131126
10
10020 ENGLISH
sPeCIfICaTIoNs
Performance specifications
– Rated Pull 2,000 lb . (907 kg)
– Gear Reduction Ratio 171:1
– Motor Permanent Magnet 1 .2 HP/0 .9 kW (12V DC)
– Duty Cycle Intermittent
– Drum Size 1 .5 in . (D) x 3 .2 in . (L) [38 mm(D) x 80 mm(L)]
– Cable 5/32 in . (D) x 49 ft . (L) [4 mm(D) x 15 m(L)]
– Gross Weight 20 .9 lb . (9 .5 kg)
– Net Weight 18 .7 lb . (8 .5 kg)
– Height 4 .4 in . (112 mm)
– Width 4 .4 in . (112 mm)
– Length 12 .9 in . (328 mm)
– Bolt Pattern 4 .9 in . x 3 in . (124 mm x 76 mm)
Line Speed and Motor Current (First Layer)
Line Pull LB 0 500 1000 1500 2000
KG 0 227 454 680 907
Line Speed (12V DC) FPM 9 .84 8 .20 6 .56 5 .58 4 .27
MPM 3 .0 2 .5 2 .0 1 .7 1 .3
Motor Current (12V DC) A 15 40 65 100 140
Running Time* Minutes 1 1 1 1 1
Cooling Time** Minutes 5 5 5 5 5
Line Pull and Cable Capacity Per Layer
Line of Cable 1 2 3 4 5
Rated Line Pull LB 2000 1630 1380 1190 1050
KG 907 739 626 540 476
Cable Capacity FT 8 17 27 .6 39 .4 49
M 2 .4 5 .2 8 .4 12 15
*If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down for 5 minutes .
Do not pull for more than one minute at or near the rated load .
**Electric winches are designed and made for intermittent use and should not be used in constant duty applications .
It is recommended to use double line and snatch block for pulling loads over
1000 lb . (454 kg) .
