Parts list
# Part Number
Description
Qty
1
300100-BF
Motor - Black Flat
1
2 300200-BF
Stationary Gear
Housing Assembly -
Black Flat
1
3 300025-N
Support Ring
1
4 300300-N
Gear Carrier
Assembly
1
5 300001-N
T-Series Rotator
Gear
1
6 300002-BF
Drum Support Plate
- Black Flat
1
7 300003
Washer ø5, Locking
4
8 300004
Screw M5×12
4
9 300005-N
Drum Support
Bushing
1
10 300400-C
Clutch Assembly
1
11 300006
Spring
1
12 300007-N
Drum Assembly
1
13 300008
Screw M5 x 8
1
14 300010-N
T-Series Bushing
1
15 300012
Tie Bar
2
# Part Number
Description
Qty
16 300013-BF
T-Series Base Plate -
Black Flat
1
17 300500-C
T-Series F/W Knob
1
18 300016
Cap Screw M6×16
2
19 300018
Screw M8×35
2
20 300019
Washer ø8, Flat
4
21 300020
Washer ø8, Locking
4
22 300021
Nut M8
4
23 300022
Hand Saver Bar
1
24 300600
Switch Assembly –
Black
1
25 300700
Cable Assembly
1
26 300800
Snatch Block
1
27 410022
Yellow Strap
1
28 301100
D-Shackle
1
29 300023-BF
Mounting Channel -
Black Flat
1
30 301000-BF
Roller Fairlead -
Black Flat
1
31 300024
Cap Screw M8×20
2
32 C20002
1/4 in . Clevis Hook
1
