sPeCIfICaTIoNs
Performance specifications
–
Rated Pull
3,000 lb . (1361 kg)
–
Gear Reduction Ratio
153:1
–
Motor
Permanent Magnet 1 .3 HP/1 kW (12V DC)
–
Duty Cycle
Intermittent
–
Drum Size
1 .2 in . (D) x 2 .9 in . (L) [31 .5 mm(D) x 73 mm(L)]
–
Cable
3/16 in . (D) x 45 .9 ft . (L) [4 .8 mm(D) x 14 m(L)]
–
Gross Weight
24 .3 lb . (11 kg)
–
Net Weight
22 lb . (10 kg)
–
Height
4 .3 in . (10 .8 cm)
–
Width
4 .3 in . (11 cm)
–
Length
12 in . (30 .4 cm)
–
Bolt Pattern
3 .1 in . (79 .5 mm)
Line Speed and Motor Current (First Layer)
Line Pull
LB
0
1000
2000
3000
KG
0
454
907
1361
Line Speed (12V DC)
FPM
11 .2
8 .8
7 .2
3 .9
MPM
3 .4
2 .7
2 .2
1 .2
Motor Current (12V DC)
A
15
80
120
150
Running Time*
Minutes
1
1
1
1
Cooling Time**
Minutes
5
5
5
5
Line Pull and Cable Capacity Per Layer
Line of Cable
1
2
3
4
5
6
Rated Line Pull
LB
3000
2373
1962
1673
1470
1290
KG
1361
1077
891
759
667
585
Cable Capacity
FT
5 .6
12 .1
19 .7
27 .9
37 .1
45 .9
M
1 .7
3 .7
6 .0
8 .5
11 .3
14 .0
*If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down
for 5 minutes . Do not pull for more than one minute at or near the rated load .
**Electric winches are designed and made for intermittent use and should not be used in constant
duty applications .
It is recommended to use double line and snatch block for pulling loads over
1500 lb . (680 kg) .
