Parts list
Parts list
#
Part Number
Description
Qty
1
450100-BF
Motor Assembly-Black Flat
1
2
450001
Coupling, I
1
3
450002
Spring, Coupling
1
4
450003
Coupling, II
1
5
450200-BF
Drum Assembly-Black Flat
1
6
450004-BF
Gear Housing / End
Bearing-Black Flat
1
7
450005-A
Gear Ring
1
8
450006
Gear Carrier Assembly,
Output
1
9
450007
Gear Carrier Assembly,
Intermediate
1
10
450008
Gear Carrier Assembly,
Input
1
11
450009
Gear-Input, Sun
1
12
450010-BF
Gear, Fixed-Black Flat
1
13
250021
Clutch Bushing
1
14
250002
Washer ø6, Flat
6
15
450011
Bolt M6x25
4
16
450012
Bolt M6x100
2
17
450013
Seal
2
18
450014
Friction Washer
2
19
450015
Retaining Ring
1
20
450016
O-Ring Seal
1
21
450017
Drum Bushing
2
22
450018
Hexagonal Shaft
1
23
450019
Tie Bar ø10
2
24
450700
Cable Assembly
1
25
450020
1/4 in . Clevis Hook
1
26
410022
yellow Strap
1
27
450021
Bolt M8x25
4
28
300020
Washer ø8, Locking
4
29
300019
Washer ø8, Flat
4
#
Part Number
Description
Qty
30
450022-BF
Mounting Channel-Black
Flat
1
31
450023
Bolt M10x20, Square
Neck
2
32
250036
Locking Nut M10
2
33
450024-BF
Roller Fairlead-Black Flat
1
34
450500
Switch Assembly
1
35
300022
Hand Saver Bar
1
36
450025
Tie Bar ø8
1
37
450026
Bolt M4x25
2
38
450027
Washer ø4, Locking
2
39
450031
Cross Recess Pan Head
Screw M6 x 8
1
40
450029
Spring
1
41
GB2760BB06002-SS
Radial Ball Bearing 6002
Sealed
1
42
250019
Axis Support Bushing
1
43
450032
Cam Clutch Gear
1
44
250012
Spring
1
45
450033-BF
Clutch Cover-Black Flat
1
46
GB2760BB16002-SS
Radial Ball Bearing 16002
Sealed
1
47
250016-BF
Clutch Cap-Black Flat
1
48
250011
Retaining Ring Clip
1
49
250017
Locking Washer ø6
1
50
250018
Cap Screw M6 x 16
1
