sPeCIfICaTIons
Performance specifications
–
Rated Pull
4500 lb . (2041 kg)
–
Gear Reduction Ratio
166:1
–
Motor
Permanent Magnet 1 .6 HP/1 .2 kW (12V DC)
–
Drum Size
2 in . (D) x 4 .9 in . (L) [50 .8 mm (D) x 125 mm (L)]
–
Cable
1/4 in . (D) x 52 ft . (L) [6 mm (D) x 16 m (L)]
–
Gross Weight
35 .3 lbs (16 kg)
–
Net Weight
32 .2 lbs (14 .6 kg)
–
Height
5 in . (12 .7 cm)
–
Width
4 .6 in . (11 .6 cm)
–
Length
16 .3 in . (41 .5 cm)
–
Bolt Pattern
6 .6 in . X 3 in . (16 .8 cm X 7 .6 cm)
Line Speed and Motor Current (First Layer)
Line Pull
LB
0
1000
2000
3000
4500
KG
0
454
907
1361
2041
Line Speed (12V DC)
FPM
12 .8
9 .8
8 .5
6 .9
3 .9
MPM
3 .9
3 .0
2 .6
2 .1
1 .2
Motor Current (12V DC)
A
28
80
130
180
280
Running Time
Minutes
1
1
1
1
1
Cooling Time
Minutes
5
5
5
5
5
Line Pull and Cable Capacity Per Layer
Line of Cable
1
2
3
4
Rated Line Pull
LB
4500
3841
3310
2907
KG
2041
1742
1501
1319
Cable Capacity
FT
13 .4
28 .8
45 .8
52
M
4 .1
8 .8
14
16
*If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down for 5 minutes .
Do not pull for more than one minute at or near the rated load .
**Electric winches are designed and made for intermittent use and should not be used in constant duty applications .
