REV 92050-20131216
18
92050 ENGLISH
SPECIFICATIONS
When temperature is below 0ºC (32ºF) use
universal tractor/transmission fluid .
NOTE
Oil
Use 10W-30 automotive oil .
Oil capacity is 0 .6 L (0 .6 qt) .
DO NOT OVERFILL .
Please reference the following chart for recommended
oil types for use in the log splitter .
Fuel
Fuel capacity is 2 L (0 .5 gallons) . Use regular unleaded
gasoline with a minimum octane rating of 85 and an
ethanol content of less than 10% by volume .
Log Splitter Specifications
– Ram Force 20 Ton
– Max Cycle Time 17 seconds
– Hydraulic Tank Capacity 15 .1 L (4 gal .)
– Max Log Length 60 .3 cm (23 .8 in .)
– Max Log Weight 45 kg (100 lb .)
– Coupler Ball Size 5 .1 cm (2 in .)
– Tire Size 40 .6 cm (16 in .)
– Max towing speed 72 km/h (45 MPH)
– Engine 208cc, OHV, 4 stroke
– Cylinder size 10 cm x 57 .5 cm
(3 .9 in . x 22 .6 in .)
– Cylinder rod size 4 cm (1 .6 in .)
– Hydraulic Fluid Type 10W AW32,
. . . . . . . . . . . . . . . . . . . . . . ASLE H-150, ISO 32
– Gear Pump 2-stage
– Max pressure 3600 psi
– Max flow capacity 30 .3 LPM (8 GPM)
– Control Valve Detent (auto-return)
– Overall Dimensions
– Gross Weight 200 kg (440 .9 lb .)
– Net Weight 180 kg (396 .8 lb .)
– Height 116 .5 cm (45 .9 in .)
– Width 103 .5 cm (40 .7 in .)
– Length 218 cm (85 .8 in .)
Maintenance Valve Clearance
– Intake: 0 .10 – 0 .15 mm (0 .004 – 0 .006 in .)
– Exhaust: 0 .15 – 0 .20 mm (0 .006 – 0 .008 in .)
Note: Tech bulletin regarding the valve adjustment
procedure is on www .championpowerequipment .com .
Spark Plugs
OEM spark plug: NHSP F6RTC
Replacement spark plug: NGK BPR6ES or equivalent
Make certain the spark plug gap is 0 .6 - 0 .8 mm or
(0 .024 - 0 .031 in .) .
Hydraulic Oil System
Oil capacity is 18 .9 L (5 gallons) .
Use types 10W AW32, ASLE H-150, ISO32 or universal
hydraulic fluid .
Engine Specifications
– Model 170F
– Displacement 208cc
– Type 4-Stroke OHV
– Start Type Recoil
Oil Cont’d.
