Part number description qty – Champion Power Equipment 46595 User Manual
Page 25
REV 46595-20130329
22
46595
ENGLISH
# Part Number
Description
Qty
1
GB5789-86-FB6-8
Flange Bolt M6x8
5
2
ST160F-1061200
Recoil Starter Knob
1
3
ST160F-1061100-Q
Recoil Starter Housing
1
4
ST160F-1061005
Recoil Starter Spring
1
5
ST160F-1061009
Recoil Starter Rope
1
6
ST160F-1061001-A
Recoil Starter Reel
1
7
ST188F-1060006
Spring, Ratchet
2
8
ST188F-1060005
Starter Ratchet (Metal)
2
9
GB5789-86-FB6-12
Flange Bolt M6x12
9
10
ST188F-1060003
Ratchet Guide
1
11
ST188F-1060004
Ratchet Guide Spring
1
12
ST188F-1060002
Screw, Ratchet Guide
1
13
ST168F-1080100-G
Fan Cover Assembly
1
14
ST160F-1050010
Nut M14
1
15
ST160F-1060001-A
Start Hub
1
16
ST168F-1080001
Cooling Fan
1
17
ST168F-1120100
Fly Wheel
1
18
ST168F-1080200
Air Guide
1
19
ST168F-1030100
Oil Seal
2
20 GB5789-86-FB6-15
Flange Bolt M6x15
4
21
ST160F-1030003
Drain Bolt
2
22 ST160F-1030004
Washer, Drain Bolt
2
23 ST168F-2-1030012-G
Crankcase
1
24 GB/T-276-94
Radial Ball Bearing 6205
2
25 ST160F-1127000-A
Oil Level Sensor
1
26
ST160F-1110108
Washer, Governor
1
27
ST160F-1110101
Governor Gear
1
28 ST160F-1110102
Pin, Weight
2
29 ST160F-1110104
Shaft, Governor Gear
1
30 ST160F-1110103
Circlip, Governor Gear
1
31
ST160F-1110107
Governor Weight
2
32
ST02FD-1151201A
Choke Lever
1
33 ST160F-1110105-A
Bushing, Governor
1
34 ST168FD-2-1050001-A
Crankshaft Assembly
1
35
ST168F-1030008-G
Gasket, Crankcase
1
36 ST160F-1030001-B
Oil Dipstick
1
37
ST160F-1030002
Gasket, Oil Dipstick
2
38 GB5789-86-FB8-32
Flange Bolt M8x32
6
39
ST168F-1110005
Spring, Throttle Return
1
40 ST168F-1110007
Spring, Governor
1
41
ST160F-1110003
Arm, Governor
1
42 GB6177-86
Nut M6
3
43 ST160F-1110008
Pin, Shaft
1
44 ST160F-1110001
Shaft, Governor Arm
1
45 ST168F-1110006
Rod, Joint
1
46 ST160F-1110004
Bolt, Governor Arm
1
47
GB5789-86-FB6-25
Flange Bolt M6x25
2
48 ST160F-1123000-G
Ignition Coil
1
49
152FMD-1001007
Dowel Pin Ø10x16
2
50 GB5789-86-FB8-55
Flange Bolt 8x55
4
51
ST168FD-1090200-G
Cover, Air Cleaner
1
52
ST168FD-1090004
Element
1
53 ST168FD-1090003
Separator
1
# Part Number
Description
Qty
54 ST168FD-1090002
Air Cleaner Seal
1
55
ST168FD-1091000-
CARB
Base, Air Cleaner
1
56 ST160F-1130003-CPE
Gasket, Carburetor
1
57
ST168F-1130001
Insulator, Carburetor
1
58 ST168F-1130002-CPE
Gasket, Insulator
1
59
ST160F-1010001
Stud Bolt M6x110
2
60 ST168F-2-1010100-G
Cylinder Head
1
61
ST168F-2-1030009-G
Gasket, Cylinder Head
1
62 ST168F-1040002
Valve, Intake
1
63 ST168F-1040006
Valve, Exhaust
1
64 ST168F-2-1040013
Lift, Valve
2
65 ST168F-2-1041000
Camshaft Assembly
1
66 ST168F-1030015-G
Dowel Pin Ø9x14
2
67
ST168FD-1080200-
CARB
Air Shroud, Cylinder
1
68 GB1099-79
Key
1
69
ST168FD-1030007-G
Crankcase Cover
1
70
ST168F-1050100
Connecting Rod Assembly
1
71
ST168F-1050003
Wrist Pin
1
72
ST168F-1050004
Circlip, Wrist Pin
2
73 468.050005.01
Piston
1
74
468.050300.01
Ring
1
75
ST168F-1080002-GC
Shroud, Cylinder Head
1
76
GB900-88
Stud Bolt
2
77 ST168F-1040005
Push Rod
2
78
ST168-1040014-A
Oil Seal, Valve
2
79 ST168F-1040027
Stud Bolt, Rocker Arm
2
80 168.040201.34
Retainer, Rocker Arm
1
81
GB6183-86-N6
Nut M6
2
82 168.040004.34
Guide, Push Rod
1
83 ST168FD-1020011-A
Breather Tube
1
84 ST168F-1020100-C
Cylinder-Head Cover Assembly
1
85 ST160F-1020002-A
Gasket, Cylinder Cover
1
86 ST160F-1040024
Adjusting Screw
2
87 ST160F-1040025
Lock Nut
2
88 ST160F-1040022
Rocker Arm
2
89 168.040202.34
Shaft, Rocker Arm
1
90 ST160F-1040008
Rotator, Exhast Valve
1
91
ST160F-1040001
Retainer, Intake Valve
1
92
ST160F-1040007
Retainer, Exhaust Valve
1
93
ST160F-1040003
Spring, Valve
2
94 ST160F-1124000
Spark Plug
1
95
ST168FD-2-1131000
Carburetor
1
96 ST168FD-1130004-CPE Gasket, Carburetor
1
97
GB97.1 6
Washer Ø6
2
98
468.131017.05
Standard Main Jet
1
ST168FD-2-1131000-
17Z1
468.131017.03
Altitude, Main Jet
/
ST168FD-2-1131000-
17Z
468.131017.04
Altitude, Main Jet
/
ST168F-2-1131000-17Z
