Parts list, Part number description qty – Champion Power Equipment 46595 User Manual
Page 23
REV 46595-20130329
20
46595
ENGLISH
Parts List
# Part Number
Description
Qty
1
ST168FD-2-G
Engine
1
2
ST02FD-02100011
Build Up-B
1
3
ST02FD-02100012
Build Up-A
1
4
504.191100.04
Rotor Comp
1
5
ST02FD-02100005-2.5
Flange Bolt M8×233
1
6
GB96 8
Washer Ø8
1
7
GB7244 8
Lock Washer Ø8
1
8
504.191200.04
Stator Assembly
1
9
ST02FD-02100002
Stator Cover
1
10
ST02FD-02100003
End Housing
1
11
ST02FD-02100001-2.5
Flange Bolt M6×158
4
12
GB97.1 6
Washer Ø6
6
13
GB93 6
Lock Washer Ø6
10
14
ST02FD-02100009
Bursh Assembly
1
15
ST02FD-02100008
Bursh Support Plate
1
16
GB93 5
Lock Washer Ø5
5
17
GB5783 M5×16
Bolt M5×16
1
18
GB97.1 5
Washer Ø5
2
19
GB5783 M5×16
Bolt M5×16
2
20 ST02FD-02100007-CPE AVR,Small
1
21
GB16674 M5X16
Flange Bolt M5×16
2
22 ST02FD-02100004
Generator End Cover
1
23 GB16674 M5X12
Flange Bolt M5×12
2
24 ST02FD-02100010
Terminal
1
25 ST02FD-1150200
Muffler Stay
1
26
GB5789 M8X20
Flange Bolt M8×20
3
27
ST02FD-1150100
Muffler Support Bracket
1
28 GB5789 M6X12
Flange Bolt M6×12
10
29 GB818 M5X15
Screw M5×15
2
30 ST188FD-1100010-88
Plate,Spark Arrester
1
31
ST188FD-1180121
Spark Arrester
1
32
ST168FD-1102000-A2
Muffler
1
33 ST02FD-03030400
Muffler Cover
1
34 GB6175 M8
Nut M8
2
35
GB93 8
Lock Washer Ø8
2
36 GB848 8
Washer Ø8
2
37
ST168F-1100200-G
Muffler Gasket
1
38 ST168FD-1090006-A
Holder, Air Cleaner
1
39
GB5789 M6x8
Flange Bolt M6×8
1
40 504.070011.01
Pipe,Fuel
1
41
ST160F-1070001
Clamp
2
42 504.070500.01
Fuel Cleaner
1
43 504.070011.00
Pipe,Fuel
1
44 ST160F-1070006A
Clip
2
45 ST02FD-04160000
Pet Cock
1
46 504.071000.35
Fuel Tank
1
47
ST02FD-04100010
Mount Vibration, Fuel Tank
4
48 ST02FD-04100014
Washer Ø6
4
49
GB93 6
Locking Washer Ø6
4
50 GB5789 M6×20
Flange Bolt M6×20
4
51
ST168F-1070006A
Fuel Filter
1
52
168.070100.01
Fuel Tank Cap
1
53 168.070014.01
Pipe,Reversal Valve
1
54 168.070026.00
Breather tube orifice
1
# Part Number
Description
Qty
55 ST160F-1070007
Clamp
1
56
ST168FD-1070400-
CARB
Rollover Valve
1
57
GB819 M5×10
Screw M5×10
2
58
ST02FD-04120000-
CARB
Fuel Meter Assembly
1
59
GB5789 M8×45
Flange Bolt M8×45
2
60 GB6177 M8
Nut M8
14
61
ST02FD-1151400(F)
Handle
1
62
ST168FD-1070408-
CARB
Clamp
2
63 ST02FD-03221002
Flange Bolt M6×12
8
64 ST02FD-03221001(Y)
Wing, Fuel Tank
2
65 504.201100.56(F)
Frame
1
66 GB5782 M10×105
Bolt M10×105
2
67
GB96 10
Flat Washer Ø10
2
68 ST02FD-03621001
Bush Ш10.5Ч58.5
2
69
ST177FD-1152300(Y)
8in Wheel
2
70
GB6182 M10
Nut M10
2
71
504.201200.00
Motor Mount I
2
72
504.201200.01
Motor Mount II
2
73 GB6177 M6
Nut M6
1
74
ST02FD-02100013-2.5
Grounding Line
1
75
GB5789 M8×16
Flange Bolt M8×16
2
76
ST05FD-03020301-
60(B)
Support Leg(2.36)
1
77 ST188FD-1743002-C
Vibration Mount
2
78
GB5789 M8×25
Flange Bolt M8×25
2
79 2C41
Control Panel
1
80 ST02FD-05702004
Ignition Switch
1
81
DP03-00000000
Intelligauge,120V
1
82 GB823 M4×14
Screw M4×14
8
83 GB848 4
Flat Washer Ø4
8
84 GB859 4
Lock Washer Ø4
8
85 GB6177 M4
Nut M4
8
86 ST02FD-05502020
L5-30R Receptacle
1
87 ST02FD-05502029
TT-30R Receptacle
1
88 ST02FD-05502023
Receptacle 5-20R Duplex
1
89 GB5783 M6×22
Bolt M6×22
1
90 GB6175 M6
Nut M6
2
91
ST02FD-05212001
Grommet
1
92
ST02FD-05202003
Sheath,Wire
1
93
ST02FD-05212002
Grommet
1
94 OV01-00000000
Over Voltage Protector
1
95
GB823 M5×14
Screw M5×14
1
96 GB823 M3×6
Screw M3×6
4
97
GB859 3
Lock Washer Ø3
4
98 GB848 3
Flat Washer Ø3
2
99 ST02FD-05302003-20
20A AC Circuit Breaker
1
100 ST02FD-05302003-25
25A AC Circuit Breaker
1
101 ST02FD-05202003
Control Box
1
102 ST188FD-1020001
Ring
1
103 GB97.1 5
Washer Ø5
3
104 GB818 M5×38
Screw M5×38
3
105 GB862 6
Washer Ш6
1
