Back-Up and License Plate Lamps
To replace the back-up and/or license plate lamps,
use the following procedure:
1. Open the liftgate.
2. Remove the liftgate trim panel on the interior of the
liftgate by pulling the trim panel snap-in fasteners
out of the retainers and also by using a tool to
remove the screw on the bottom right side of the
trim panel.
3. Disconnect the courtesy lamp electrical connector
on the trim panel.
4. Use a tool to remove the five nuts on the back of
the license plate applique assembly.
5. Remove the license plate applique assembly from
the liftgate by pulling the assembly rearward to
disengage the two snap-in retainer clips at the back
of the license plate applique assembly near the
liftgate panel.
6. For the back-up lamp, turn the bulb socket
one-quarter turn counterclockwise to remove.
For the license lamp, slide the license lamp
assembly out of the license plate applique
assembly, and turn the bulb socket one-quarter
turn counterclockwise to remove.
7. Replace the bulb. See Replacement Bulbs on
page 5-55 for the proper bulb number.
8. Reverse Steps 1 through 6 to reinstall the license
plate applique assembly.
Replacement Bulbs
For any bulb not listed here contact your dealer.
Exterior Lamp Bulb Number
Back-Up Lamp 3157KX
Fog Lamp 9145
Front Sidemarker W5WLL
Front Turn Signal Lamp/DRL
GM Part No.
10319395
Headlamp High-Beam 9005XS LL
Headlamp Low-Beam 9006XS LL
Parking Lamp
With Halogen Low Beam W5WLL
With HID Low Beam W5W B50X2
5-55
