Fuses Usage
RT PARK
Passenger’s Side Taillamp
Assembly, Front Sidemarker and
Front Parking Lamp Assembly
HORN Dual Horn Assembly
LT HI BEAM Driver’s Side High-Beam Headlamp
LT LOW BEAM Driver’s Side Low-Beam Headlamp
RT LOW BEAM
Passenger’s Side Low-Beam
Headlamp
RT HI BEAM
Passenger’s Side High-Beam
Headlamp
TOS
Manual Transmission Output Speed
Sensor
SPARE Not Used
THEFT
ECM (Electronic Control Module),
TCM (Transmission Control Module),
PASS-Key
® III+ Module
LT PARK
Driver’s Side Taillamp Assembly,
Front Sidemarker and Front Parking
Lamp Assembly
DIMMING
Rear License Plate Assembly,
Dash Integrated Module (DIM)
DIM/ALDL
DIM, ALDL (Assembly Line
Data Link)
FLASHER Turn Signal/Hazard Flasher Module
Fuses Usage
ECM Electronic Control Module
STRG CTLS
Steering Wheel Control Pad,
Headlamp Switch
HTR VLV/
CLTCH
Heater Valve, Clutch Switch (Normal
Closed), Clutch Switch (Normal
Open), Jumper to Start Relay Coil
for Automatic Transmission
WASH NOZ
Driver’s and Passenger’s Side
Heated Washer Nozzles
PRE O2/CAM
Driver’s & Passenger’s Side
Oxygen Sensors, CAM Phaser,
Canister Purge
TCM/IPC
TCM, ECM and IPC (Instrument
Panel Cluster)
SPARE Not Used
IGN MOD/MAF Front Bank Ignition Modules
ELEC PRNDL Electronic PRNDL
SPARE Not Used
SPARE Not Used
IGN SW
Ignition Switch (Power to IGN-3
and CRANK)
VOLT CHECK DIM (Dash Integration Module)
