Fuses Usage
IGN SW
Ignition Switch
(Power to IGN-3 and CRANK)
VOLT CHECK DIM
ECM/TCM
ECM, TCM, IPC, PASS-Key ® III+
Module
WPR MOD Windshield Wiper Module Assembly
POSTO2 Post O2 Sensors
COMP CLUTCH Compressor Clutch
WPR SW Windshield Wiper/Washer Switch
FOG LAMP Fog Lamps
OUTLET
Center Console Accessory
Power Outlet
EVEN COILS Even Injection Coils
Fuses Usage
I/P OUTLET
Instrument Panel Accessory
Power Outlet
CCP Climate Control
PREO2/CAM
Driver’s and Passenger’s Side
Oxygen Sensors, CAM Phaser
SPARE Not Used
SPARE Not Used
SPARE Not Used
Circuit
Breakers
Usage
HDLP WASH
C/B-OPT
Headlamp Washer Motor (Optional)
5-97
