Relays Usage
HI BEAM
RELAY MICRO
High-Beam Headlamps
DRL RELAY
MICRO-OPT
Daytime Running Lamps
LO BEAM
RELAY/HID
MINI-OPT
Low-Beam HID Headlamps (Option)
HDLP WASH
RELAY
MINI-OPT
Headlamp Washer Motor (Option)
SPARE Not Used
BLOWER
RELAY MINI
Front Blower
FOG LAMP
RELAY MICRO
Fog Lamps
MAIN RELAY
MICRO
Powertrain/ECM
STARTER
RELAY MINI
Starter Solenoid
CMP CLU
RELAY MICRO
Compressor Clutch
IGN-1 RELAY
MICRO
Ignition Switch (ON)
Wiring
Harnesses
Usage
BODY W/H Wiring Harness Connection
I/P W/H Wiring Harness Connection
ENG W/H Engine Wiring Harness Connection
FORWARD
LAMP
Forward Lamp Wiring Harness
Connection
J Cases Usage
R REAR
RRPDB (Passenger’s Side Rear
Power Distribution Box)
R REAR
RRPDB (Passenger’s Side Rear
Power Distribution Box)
L REAR
LRPDB (Driver’s Side Rear Power
Distribution Box)
L REAR
LRPDB (Driver’s Side Rear Power
Distribution Box)
HI FAN High Cooling Fan Motor
LOW FAN Low Cooling Fan Motor
BLOWER PWM Fan Motor Assembly
STARTER Starter Solenoid
EBCM Electronic Brake Control Module
5-95
