Burris Veracity - Manual (Page 11)

Ballistic E1 FFP Varmint Reticle
Front Focal Plane Reticle
The Ballistic E1 FFP Varmint reticle is calculated in
MOA (minute of angle) measurements. The Varmint
reticle provides a very precise platform for measuring
distance and determining target size by providing
MOA tick marks across the horizontal crosshair and
across the upper portion of the vertical crosshair.
Trajectory compensation has been calculated out to
700 yards with wind dots representing a 10 MPH wind
adjustment at every hash mark below the vertical
center point. The bolder crosshairs make this reticle
highly usable in the FFP design, ensuring that the
reticle is still visible on low power. The FFP also allows
the trajectory compensation technology to be used at
any magnification, a nice advantage over Rear Focal
Plane reticle designs that can only provide trajectory
compensation on high power.
Reticle Subtensions
Reticle
Model Units A B C D E F G H I J K
Ballistic
4x-20x MOA 2 40 2 .38 1 4 .13 2 4 .23 .13
E1 MOA
Ballistic
5x-25x MOA 2 40 2 .30 1 4 .11 2 4 .18 .11
E1 MOA
10
B
A
C
D
E
F
G
H
I
J (dot diameter)
K
Y
a
rd
s
M
O
A
In
ch
e
s
@
1
0
0
Y
a
rd
s
300
400
500
600
700
-1.53
-3.56
-6.09
-9.23
-13.14
-1.60
-3.73
-6.38
-9.67
-13.77
Trajectory
Line Length
in MOA
1.0
4.0
2.5
6.0
Windage Dot
Center from
Vertical Center in
MOA
2.74
3.87
5.15
6.62
Close-Up of MOA Crosshairs
2
4
.5
2
1
4
Reticle Center = 200 yards
