Buick 2006 Lucerne - Manual (Page 301)

3.1. Clean the area around the engine oil fill tube
and cap before removing. Twist the oil fill
tube, with cap attached, counterclockwise
and remove it.
3.2. Lift the engine cover shield at the front, slide
the catch tab out of the engine bracket and
remove the cover shield.
3.3. Put the oil fill tube, with cap attached, in the
valve cover oil fill hole until you are ready to
replace the cover shield.
4. After the engine cools,
open the coolant air
bleed valve. There
is one bleed valve. It is
located on the
thermostat housing.
5. Fill the radiator with the proper DEX-COOL ® coolant
mixture, up to the base of the filler neck. See
Engine Coolant on page 5-23 for more information
about the proper coolant mixture.
If you see a stream of coolant coming from an air
bleed valve, close the valve. Otherwise, close
the valve after the radiator is filled.
6. Rinse or wipe any spilled coolant from the engine
and the compartment.
7. Replace the 3800 Series II V6 engine cover shield.
7.1. Remove the oil fill tube, with cap attached,
from the valve cover.
7.2. Insert the catch tab on the cover shield
under the bracket on the engine.
7.3. Place the hole in the cover shield over the
hole in the valve cover. Install oil fill tube and
cap by twisting clockwise.
5-33
2006 - Buick Lucerne Owner Manual
