Buffalo Filter VisiClear - Manual (Page 21)

21 Buffalo Filter® VisiClear™ Operator’s Manual
2.4 Performance References*
Performance
Model Number VisiClear™
Maximum Flow Setting (CFM-U.S.)
Standard Hose I.D.
7/8” 30 CFM **
3/8” 4.6 CFM
1/4” 1.9 CFM
Standard Hose I.D.
22 mm 850 LPM **
9.5 mm 130 LPM
6.4 mm 54 LPM
Dimensions (H x W x D ) inches 7 x 14 x 16
Dimensions (H x W x D ) centimeters 17.8 x 35.6 x 40.6
Weight lbs (kg) 17 lbs (7.7 kg)
Noise Level, dBA MAXIMUM 55 dBA
Footswitch Pneumatic Standard
Remote Control Activation YES (optional)
Safety Features UL Classified
CE Marked
Fuse protection
Display Touch Screen
Filter Status
Flow Rate
Service Information
Voltage Available 100/120 VAC, 220/240 VAC
Frequency, auto sensed 50/60 Hz
Variable Flow Control Yes
Motor Watts 1000 ± 10%
Motor Static Suction kPa (6.5 mm orifice) 25.69
*For reference purposes only
**Using a new 7/8 in x 6 in (22 mm x 1.8 m) hose
