Operation

-14-

Q-Wash 260-LED User Manual Rev. 05

System Default

To default all the product’s parameters to their default values, do the following:

1. Go

to

MENU > EXTRA.

2. Press

(PASSWORD) will show on the display.

3. Press

(**** will show on the display).

4. Enter the password, as explained in Keylock (CALIB will show on the

display).

5. Use

to select DEFAULT.

6. Press

(NO will show on the display).

7. Select

YES and press to default the product or press

to

exit.

Edit Custom

This function allows you to program up to 255 steps in a single custom program.

1. Go

to

MENU > EDIT.

2. Press

to go to STEP.

3. Press

to select a value. The current value (001~255) will show on

the LCD.

4. Press

or to select a new value.

5. Press

to accept the value.

6. Press

to go to PAN.

7. Repeat steps “1” through “6” for TILT, SPEED, RED, GREEN, BLUE,

DIMMER, STROBE, DIMSPEED, and TIME.

8. Press

to go to USE.

9. Select

YES to save the settings for this step or NO to delete them.

10. Repeat steps “3” to “8” for the other steps.

The product will execute all the steps in the CUSTOM program and it will stop.

To make the product start over add a last step whose duration is 0 seconds.

Example:

Step 1:

Time = 5

Use = Yes

Step 2:

Time = 4

Use = Yes

Step 3:

Time = 6

Use = Yes

Step 4:

Time = 0

Use = Yes

(This step creates a loop)

Step 5:

Time = 0

Use = No


(Unused

steps)

Step 255

Time = 0

Use = No
