Boekel Scientific 140384T1 Microplate Replicators - Manual (Page 2)

Please use the handle when flame sterilizing as the base plate will get hot and can
cause injury.
CLEANING PROCEDURES
It is recommended that the replicator pins be rinsed in a solvent such as acetone or
one similar to the type of sample being used and then DI rinsed to remove any foreign
material. If the substance being replicated is sticky or thicker than water, then a
cleaning with a fine nylon or wire brush can be used in addition to the solvent. It is
best to rinse and pat dry with a soft cloth after using a brush. Since the replicator pins
are generally what are coming in contact with the transfer liquid, it is recommended
that only the pins be cleaned by the above method. DO NOT IMMERSE the entire
replicator in a bath or washer as it could damage or dislodge the pins. DO NOT USE
WITH A SONICATOR OR PUT IN AN ULTRASONIC CLEANER.
Caution: If a wire pad or brush is used it can remove material from the pins and
change the flatness or the face and negatively affect the liquid transfer.
SPECIFICATIONS
96 Pin Replicator
140500
48 Pin Replicator
140501
384 Pin Replicator
140384
Template
140384T1
Product Dimensions:
Width x Length x Height
11cm x 7.6cm x 11cm
(4-1/2in x 3in x 4-1/2in
N/A
Net Weight 0.6kg (1-1/4lb) 0.45kb (1lb) 0.6kg (1-1/2lb) 0.6kg (1-1/2lb)
Shipping Weight 1.5kg (1-3/4lb) 0.7kg (1-1/2lb) 0.9kg (2lb) 0.9kg (2lb)
Pin Length 2.54cm (1in) N/A
Pin Size 1.5mm x 1.5mm (1/16in x 1/16in) N/A
Pin Design Flat, Square Flat, Square Flat, Square N/A
* Note: Template is available for the 140384 replicator only. Both 140384 and 140384T1 are labeled with
“A1” for correct plate orientation. It is recommended that 2 templates are used when replicating
between two 384 plates.
