Installation Manual
Getting to Know Your LightCharge®
A. LightCharge® mounted to handlebar
B. Bottle Dynamo (included only with LightCharge® for Bottle Dynamo)
C. Dynamo Mounting Bracket (Included only with LightCharge® for Bottle
Dynamo)
D. Location of Hub Dynamo (not included)
A. LightCharge
A1 Top
A3 Charging Mode Switch
A5 USB Port and Cover
A2 Cable
A4 Mounting Slots
A6 Bottom
B
C
A
D
A1
A6
A2
A3
A4
A5
