Bike2Power iPhone 5 Power Plus User Manual
Bike console, Power plus, User guide

Bike
CONSOLE
POWER PLUS
For iPhone 5
Bike Mount with 3000mAh Battery Pack
USER GUIDE
1. Delivery Contents
B. BikeConsole
Case
E. USB to 2.5mm DC (Power In) Cable
D. Phone Case
A. Battery Pack
C. Mounting Bracket
www.tigrasport.com
F. Micro USB to USB Female
(Power Out) Cable
I. Allen
Key
G. Rubber Pad
H. Headphone
Cable
Passage Plug
3. Battery Specifications
1. Input: DC 5V 500 mA (max.)
2. Output: DC 5V 1000 mA (max.)
3. Capacity: 3000 mAh (11.1 Wh)
4. Type: 3.7V Li-ion
5. Operating temperature: -5˚ to 50˚C
6. Storage temperature: -20˚ to 60˚C
4. Battery Pack Usage
1. To start charging the phone with the built-in Lightning connector, press the power button
once. The indicator light will be turned on and stay on.
2. To stop charging the phone, press the power button again. The indicator light will be turned
off.
3. To start charging other devices using the micro USB Power OUT port, continuously press the
power button for 4 seconds. The indicator light will start flashing slowly (once every 2
seconds).
4. To stop charging other devices, continuously press the power button for 4 seconds again.
5. Whenever you start charging any devices or connect the battery pack to a compatible power
source to get it charged, the battery level indicator will be switched on. The indictor will be
in the form of a medium flash (once every 1 second), with the higher number of flashes
meaning the battery power is nearer to full:
- 1 flash: 50% or below
- 2 flashes: 51-60%
- 3 flashes: 61-80%
- 4 flashes: above 80%
After the battery level indicator is shown, the indicator light will return to its normal state.
6. When the battery pack is being charged, the indicator light will flash rapidly (once every 0.3
seconds). When the battery is fully charged, the indicator light will change to another flash
pattern (flash for 0.3 seconds, off for 3 seconds).
7. The battery pack can be charged and discharged simultaneously.
8. The power button, once switched on, can only be manually switched off.
1. Never charge the battery pack with the Power OUT port. Doing so may risk damaging the
battery pack.
2. Always keep the contact pins and contact plates clean.
3. Always switch off the battery pack (with the indicator light off) to conserve power.
4. Do not store or use battery in excess of the designed temperature ranges.
5. Do not place battery in fire.
6. Stop using if battery is damaged, excessively hot or showing other abnormalities.
7. Do not disassemble battery or attempt to repair or modify it in any manner.
8. Do not expose battery to moisture or submerge it in liquid. Keep battery dry at all times.
9. Do not charge battery other than using the built-in 2.5mm DC connector.
10. For extended storage, first charge battery for one hour.
11. Never dispose battery in the garbage.
12. Do not over-tighten mounting bracket to prevent breakage.
13. Do not bend the cover to prevent deformation.
14. The BikeConsole is designed to be splash proof only. Do not immerse it in water.
15. Make sure the BikeConsole is securely locked to mounting bracket before riding.
5. Warning
IPH-2150-M-EN
BikeConsole Power Plus for iPhone 5 is a Made for iPhone product.
“Made for iPhone” means that an electronic accessory has been designed to connect
specifically to iPhone, and has been certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards. Please note that the use of this accessory with iPhone may
affect wireless performance.
