AXEON BT-Series - Manual (Page 40)

40
BT – Series User’s Manual
MKTF - 206
06/12
BT-1500 SYSTEM PART LIST
Item No. Qty. Part No. Description
1……………2………..200901……GAUGE, BTM, NO FILL, 0-100PSI/BAR, 2” DIA
2……………1………..204913……VALVE, SOLENOID, N/C, UL, 110V, 1” FNPT
3……………1………..200640……CART, SEDIMENT, POLYPRO, 4.5”x 20”, 5 MIC
4……………1………..200663……CARTRIDGE, CARBON, BLOCK, 4.5”x 20”, 10 MIC
5……………2………..203649……HOUSING, FILTER, BLK/BLU, 4.5”x 20”, 1” FNPT
6……………1………..200898……METER, FLOW, PM, 0-5GPM, 1/2”x 1/2” MNPT
7……………1………..200897……METER, FLOW, PM, 0-2GPM, 1/2”x 1/2” MNPT
8……………1………..200904……GAUGE, BKM, FILL, 0-300PSI/BAR, 2.5” DIA
9……………1………..200862……SWITCH, ON/OFF, SINGLE POLE, 110V
10………….1………..200864……BOX, SWITCH, GANG, SINGLE, PROOF, WEATHER
11………….1………..201004……VALVE, NEEDLE, SS 316L, 1/4" FNPT, PUROTECH
12………….1………..200964……VALVE, CHECK, PP, 3/8” FNPT x 3/8” FNPT
13………….1………..200906……SWITCH, PRESSURE, LOW, N/O 15-30, 1/4” FNPT
14………….1………..201985……MOTOR, CARB, 3/4" HP, 110/220V, 50/60 HZ
15………….1………..200783……PUMP, VANE, BRASS, BYPASS, 5.3GPM, 1001
16………….2………..200376……MEM, HF1, 2540, SYSTEMS
17………….2………..200520……MHS, PVC, 2540, 3/8”x 3/8” SP FNPT, SYSTEMS
18………….4………..200593……SNAP RING, DELRIN, 2.5”
19………….2………..200591……END PLUG, OPEN, GTX, 2.5”, 3/8” FNPT
19………….2………..200592……END CLOSED, OPEN, GTX, 2.5”, 3/8” FNPT
20………….4………..200586……CLAMP, SADDLE, NYLON, BLK, 2.5”, PVC
