NOTE: YOU WILL FIND THAT THE FITTINGS HAVE BEEN PRE-INSTALLED, AS WE
HAVE PRE-ASSEMBLED AND INSPECTED IT FOR YOU IN THE FACTORY.
Charleston Style Awning Frame must be installed on the wall as there is no
connecting part between AA and TB
STEP 1: Separate all of the parts by part number so they will be easy to
assemble.
STEP 2: Top Bar (TB) must be installed first. C-Channel on the TB must be
close to the wall. Before installing the TB you must make sure that there is
enough space below the TB for the height of the awning. Example CH22 style will
need 31” of the space for the height of the awning (please see the chart below
for the height measurements).
*** all the sizes are in inches
Model
Space
between
TB and
SFB in
inches
Height
incl
valance Projection Model
Space
between
TB and
SFB in
inches
Height
incl
valance Projection
CH22 24 31 24 CH22-NV 24 24 24
CH32 36 44 24 CH32-NV 36 36 24
CH33 36 44 36 CH33-NV 36 36 36
CH34 36 44 48 CH34-NV 36 36 48
CH43 48 56 36 CH43-NV 48 48 36
CH44 48 56 48 CH44-NV 48 48 48
ECH2442 18 24 42 ECH2442-NV 24 24 42
ECH12 8 12 24 ECH12-NV 12 12 24
ECH1836 12 18 36 ECH1836-NV 18 18 36
ECH1230 8 12 30 ECH1230-NV 12 12 30
ECH1030 10 16 30 ECH1030-NV 16 16 30
ECH23 18 24 36 ECH23-NV 24 24 36
ECH24 18 24 48 ECH24-NV 24 24 48
STEP 3: Architectural Arms (AA) must be installed next. The space between Top of the
(TB) and the Bottom of the (FSB) BRACKET (the Arm will come down further than
the bracket) must be according the chart above.
STEP 4: Install the Front Bar (FB) to the projection side of the Architectural Arms (AA).
The Velcro on the (FB) must face up.
STEP 5: Install the NC (left and right) with arrows facing upwards. The holes on the
(FB) and (FB) are pre drilled. Make sure that the Velcro on (NC) facing left and right
STEP 6: If the awning is larger then 4’ (52.5”) wide then you must install additional
(NC)s and (BP)s to complete the frame assembly and installation
STEP 7: Once the frame is completely installed then secure all the joints where
connectors are attached by driving one self tapping screw from inside the frame.
