Awntech Mesa User Manual
Wh p
1
Installation Instructions for the Window Retractable Awning
MODEL
-
MESA
TYPE
-
MANUAL WINDOW RETRACTABLE AWNING
USE
-
RESIDENTIAL AND COMMERCIAL
CAUTION:
THE ARM IS SPRING LOADED. IMPROPER HANDLING CAN RESULT IN SERERE
INJURY TO THE PERSON AND MAY CAUSE DAMAGE TO THE PROPERTY.
W
H
P
W – WIDTH OF THE AWNING (top)
H - HEIGHT OF THE AWNING (Arm radius)
P – PROJECTION & THE ARM
Space – the distance between the projection arms
installation distance
(space) between the
projection arms
