Page 3
Introduction
Operated with a system having a YA-Extender cat.5 cable, this product divides a signal transmitted by
the cat.5 cable into 4/8 identical RJ-45 output signals by the RJ-45 connector input of the
YA-S4/YA-S8.
Features
Equalization length is adjustable.
YPbPr signal gain is adjustable.
Audio sample rate 48KHz.
Specifications
Function YA-S4 YA-S8
Video Support
Component / Composite Video
RJ-45 In connector
1 RJ-45
RJ-45 Out connector
4 RJ-45
8 RJ-45
Video output connector
1 set RCA(YPbPr)
Audio Support
Stereo Audio / Coaxial
Audio output connector
1 set RCA(R/L)
Coaxial output connector
1 RCA
Max. Resolution
1080p
Cable Distance
300 m (Max.)
Power Adapter (Min.)
DC 12V / 1.25A
Operating Temperature
0 ~ 50℃
Storage Temperature
-20 ~ 70℃
Humidity
0 ~ 95%
Housing Metal
Weight
476 g
675 g
Dimensions (LxWxH)
160 x 114 x 27 mm
230 x 114 x 27 mm
