Introduction
The extension of YPbPr/Audio signal device up to 300 meter away by using YA-E and one CAT5
cable.
Features
ƒ Equalization length is adjustable.
ƒ YPbPr signal gain is adjustable.
ƒ Audio sample rate 48KHz.
ƒ The format of the audio input and output can be changed.
Specifications
Function YA-L YA-E2 YA-E4
Video Support Component / Composite Video
Video input connector 1 set RCA(YPbPr)
Video output connector 1 set RCA(YPbPr)
Audio Support Stereo Audio / Coaxial
Audio input connector 1 set RCA(R/L)
Audio output connector 1 set RCA(R/L)
Coaxial input connector 1 RCA
Coaxial output connector 1 RCA
RJ-45 Out connector 1 2 4
Max. Resolution 1080p
Cable Distance 300 m (Max.)
Power Adapter (Min.) DC 12V 600mA
No Load 12V/0.16A 12V/0.21A 12V/0.35A Power
Dissipation Full Load 12V/0.16A~12V/0.22A 12V/0.21A~12V/0.32A 12V/0.35A~12V/0.53A
Operating Temperature 0 ~ 50℃
Storage Temperature -20 ~ 70℃
Humidity 0 ~ 95%
Housing Metal
Weight 458g 462g 469g
Dimensions (LxWxH) 160 x 114 x 27 mm
